Flexible printed circuit smart glow stick four-layer rigid flexible pcb flex circuit board

  • Place of origin: China
  • Material: FR-4 PI
  • Board thickness: 0.45mm
  • Offer:
  • Range of copper thickness: 0.5oz-2.0oz
Quote Now

Product Specification

1.Minimum metallized hole diameter: 0.30mm±0.075mm;

2.Minimum non-metallized hole diameter: 0.75mm±0.075mm

3.Minimum circuit width: 0.15±0.02mm; Minimum circuit spacing: 0.10±0.02mm

4.Solder Mask & Characters: Customizable

5.Finished Product Dimensions: 215*18.10*0.45mm

6.Surface Finish: Immersion Gold 1-2U

7.Product highlights:The four-layer rigid-flex PCB is made of ultra-thin materials, and the LED light board requires a white film or white oil process for design and production.

Product Application Scenarios


PCB Production Line


Contact Us

Contact us for any help regarding Rigid-Flex PCB for smart glow stick:
